GL240(Graphtec Instruments)

Elevate Your Data Collection with the Graphtec GL 240 (Graphtec Instruments)Data Logger Instrument

Features
  1. All Channel Isolation: Ensures signal integrity across channels, accommodating various inputs without interference.
  2. Multi-Type Inputs: Supports voltage, temperature, humidity, pulse, and logic signals, allowing diverse measurements.
  3. Wide Range of Measurements:
    • Voltage: 20 mV to 100 V, 1-5 V/F.S.
    • Thermocouples: Type K, J, E, T, R, S, B, N, W (WRe5-26)
    • Humidity: 0 to 100% RH with B-530 humidity sensor (optional)
    • Pulse: 4 channels for rotation count (RPM), accumulating count, instant count
    • Logic: 4 channels
  4. Maximum Sampling Interval: Offers quick sampling rates, with up to 10ms achievable for voltage measurements.
  5. Memory and Storage:
    • Built-in 4GB flash memory and SD card slot (supports up to 32GB) for extended data storage.
    • Captured data is saved in GBD or CSV file formats.
  6. Ring and Relay Capture Function:
    • Ring memory mode saves the most recent data.
    • Relay mode allows continuous data saving to multiple files up to 2GB without data loss until capturing is stopped.
  7. Hot-Swapping SD Cards: SD card replacement during data capture with intervals of 100ms or slower.
  8. Backup Recording: Scheduled creation and transfer of backup files to SD card or FTP server while recording data.
  9. Data File Verification: Checks file integrity when replaying data, ensuring data integrity.
  10. Useful Functions: Bar chart display for digital sensor data; alarm outputs based on channel conditions.
  11. USB Drive Mode: Allows data transfer to the PC using a drag-and-drop feature.
  12. Clear 4.3-inch Color LCD: Displays monitoring data in waveform or digital form, providing parameter settings.
  13. Versatile Power Options: Choose between AC, DC supply, or rechargeable battery pack.
  14. Networking Features: Web & FTP server, FTP client, and NTP client functions for network use.
  15. Accessories:
    • Cover (B-577): Protection from cosmetic damage.
    • Storage Case (B-581): Portable case for easy handling and storage of the GL240 and input cables.
Specifications & Accessory

Main Unit Specifications:

  • Analog Input Channels: 10 channels
  • Sampling Interval: 10ms to 1 hour
  • Waveform Display Time Scale: 1 sec to 24 hours per division
  • Trigger & Alarm Functions: Start/stop capturing data by trigger, with multiple trigger sources and conditions.
  • Alarm Output: Signals alarm conditions in input signals.
  • Pulse Input Functions: Rotation count (RPM), accumulating count, instant count with specific configurations.
  • Calculation Functions: Addition, subtraction, multiplication, division, statistical calculations.
  • Interface to PC: USB (Hi-speed), WLAN (with B-568 option)
  • Storage: Built-in 4GB Flash Memory, External SD card slot (up to 32GB), backup to SD card or FTP server.
  • Capturing Modes: Normal, Ring (saves recent data), Relay (saves data to multiple files).
  • Data Verification: Check-sum function verifies data file integrity.
  • Display: 4.3-inch TFT color LCD, multiple display modes available.
  • Operating Environment: 0 to 45 ºC, 5 to 85 % RH

Analog Input Specifications:

  • Input Method: Isolated balanced input for all channels.
  • Type of Input Terminal: Screw terminal (M3 screw)
  • Measurement Range: Voltage, thermocouple, humidity.
  • Measurement Accuracy: Varies based on type (e.g., ±0.1% F.S. for voltage).
  • A/D Converter: Sigma-Delta type, 16 bits.

Software Specifications for PC (GL100_240_840-APS):

  • Supported OS: Windows 7/8/8.1/10
  • Functions: Control, real-time data capture, replay, data format conversion, reporting, statistical calculations.

Software Specifications for Smart Devices (GL-Connect):

  • Supported OS: Android 4.1 to 6.0, iOS 9/10/11
  • Functions: Control, display measured data in waveform/digital form.

Wireless LAN Unit (B-568) Specifications:

  • Communication: Wireless in the 2.4GHz band, IEEE802.11b/g/n.
  • Security Protocols: WEP64, WEP128, WPA-PSK/WPA2-PSK, AKIP/AES.
  • Communication Distance: Approx. 40m.
  • Function: Access Point mode, Station mode for communication with PC/Smart devices.

Humidity Sensor B-530 (Option) Specifications:

  • Measurement Range: -25 to 80℃, 0 to 100% RH.
  • Measurement Accuracy: Varies with temperature, RH range.
  • Response Time: 15 sec (90% response with membrane filter).

Options and Accessories:

  • Includes various cables (input/output, DC drive), battery pack, shunt resistor, AC power adapter, and discontinued items like the rubber protector and storage case.

GL840 (Graphtec Instruments)

Graphtec Instruments GL840 Data Logger: Precision Meets Versatility

Features

Multifunction Analog Input Ports

  • Isolated Input System: Ensures noise-free signal integrity across 20 channels, expandable to 200 channels for voltage, temperature, humidity, logic, and pulse measurements.
  • Custom Configurability: Expand channels via optional extension units and terminals (B-566, B-564, B-565) for diverse application needs.

Optional Terminal Lineup

  • Standard (B-564): Multi-standard terminal for GL840-M model.
  • High-Voltage Precision (B-565): High-voltage, high-precision terminal for GL840-WV model.
  • Screwless (B-564SL): Speeds up wiring for multiple channels.

Digital Sensor Support

  • Seamless integration with GL100 digital sensors via dedicated terminals.

Logic/Pulse Inputs

  • 4 channels for logic/pulse signals for industrial-grade measurements.

Sampling Speed

  • Achieve up to 10ms sampling intervals for faster voltage measurements by adjusting channel usage.

Memory and Data Handling

  • 8GB Flash Memory: Supports GBD or CSV file formats.
  • Capturing Time: Long-term data storage with varying capture durations based on file formats and sampling intervals.
  • Backup and Verification: Data integrity checks and backup functions for secure recording.

Additional Functions

  • GS Sensors: Integration for temperature/humidity, AC/power, illuminance/UV measurements.
  • Alarm Output: Four-channel alarm setting based on specified conditions.
  • User-Friendly Navigation: Easy setup and operation via a 7-inch LCD.
  • Power Options: AC, DC, or rechargeable battery power sources.
  • Networking Features: Web & FTP server, FTP client, NTP client functions.

Accessories

  • Cover (B-578): Protection from minor impacts.
  • Storage Case (B-581): Portable case for convenient storage.
Specifications & Accessory

GL840 Main Unit Specifications

  • Analog Input: 20 channels in standard configuration (expandable to 200)
  • Sampling Interval: 10 ms to 1 hour
  • Trigger & Alarm: Multiple trigger sources, alarm outputs, pulse input modes
  • Interface: Ethernet, USB, WLAN (with B-568 option)
  • Storage: Internal 4GB Flash Memory, External SD card slot (up to 32GB)
  • Capturing Mode: Normal, Ring, Relay
  • Display: 7-inch TFT color LCD (WVGA: 800 x 480 dots)
  • Language: Multiple language support
  • Operating Environment: 0 to 45 ºC, 5 to 85% RH

GL840 Analog Input Specifications

  • Input Method: Isolated balanced input, voltage, thermocouple, RTD, humidity
  • Measurement Range: Voltage (20mV to 100V), various temperature ranges
  • A/D Converter: Sigma-Delta type, 16 bits
  • Maximum Input Voltage: Up to 600Vp-p (Channels (-) / (-))

Software Specifications for PC (GL100_240_840-APS)

  • Supported OS: Windows 10, 8, 7, Vista (32/64-bit edition)
  • Functions: Control GL series, real-time data capture, replay data, data format conversion
  • Settings Control: Input condition, capturing condition, trigger/alarm condition, reports
  • File Operation: Data format conversion, merging multiple data files, warning function

Software Specifications for Smart Device (GL-Connect)

  • Supported OS: Android 4.1 to 6.0, iOS 9/10/11
  • Functions: Control GL series, display measured data in waveform or digital value

Wireless LAN Unit (Option B-568) Specifications

  • Communication Method: Wireless IEEE802.11b/g/n
  • Communication Distance: Approx. 40m
  • Functions: Access Point mode, Station mode

Humidity Sensor B-530 Specifications

  • Allowable Temperature Range: -25 to 80℃
  • Allowable Humidity Range: 0 to 100% RH
  • Measurement Accuracy: Varies with temperature range

Options and Accessories

  • Input terminals (B-564, B-564SL, B-565)
  • Base units for input terminals (B-566)
  • Various cables, adapters, sensors (temperature, CO2, current, voltage), storage cases, power adapters

GL980

Redefine High-Speed Measurement Precision with the Graphtec GL980 Data Logger

Features

High-Speed Simultaneous Sampling & Isolated Inputs:

  • Simultaneous Sampling: Eight A/D converters per channel sustain maximum sampling speeds for all eight channels.
  • Sampling Interval: Ranges from 1 µs to 1 min.
  • External Sampling: Syncs sampling with an external device.
  • Multifunction Input: Simultaneous voltage, temperature, humidity, logic, and pulse measurements.

Trigger & Alarm Functions:

  • Trigger Action: Start/stop data capture by trigger.
  • Trigger Sources: Measured signal level, alarm, external, scheduled time, scheduled day, elapsed time.
  • Alarm Function: Set thresholds for each channel, output alarm signals.

LCD Monitor with Multiple Display Modes:

  • Y-T Waveform Screen: Displays analog waveform and digital values.
  • Digital Monitor Screen: Shows real-time statistical calculations.
  • Past Waveform Screen: Views past data while capturing.
  • XY Graph Monitor Screen: Emulates classic XY chart recorder.

Quick Setup & Operation:

  • Menu-Driven Interface: Six pre-set menu screens for simple operation.
  • Power Source Options: AC adapter, DC input, battery pack for stable operation.

Recording & Data Management:

  • Built-in RAM & Flash Memory: Supports long-term recording.
  • Memory Capacity: Provides approximate recording times for various sampling rates.
  • Memory Division Function: Divides built-in RAM into blocks for multiple recordings.
  • Ring & Relay Modes: Save recent data or multiple files until data capture stops.
  • CSV Format & Backup: Saves data in GBD or CSV format, backup to SD/USB/FTP server.
  • Auto Save & Search Function: Automatically saves recorded data, searches for specific values.

Network & Communication:

  • Ethernet (LAN) & USB Interface: Communicates with a PC for monitoring, file transfer, and setup changes.
  • Web Server & FTP Function: Allows control via a web browser, file transfer via FTP, and remote monitoring.
  • Email Alerts: Sends alerts for alarms, low battery, limited storage, or communication issues.

USB Drive Mode for Easy File Transfer:

  • USB Drive Mode: Simplifies data transfer to/from the PC using built-in Flash memory or SD Flash memory card.
Specifications & Accessory

Main Unit Specifications:

  • Display: 7-inch TFT color LCD (800 x 480 dots)
  • Language: Multiple options including English, French, German, etc.
  • Interface: Ethernet (10 BASE-T/100 BASE-TX), USB2.0
  • Functions: Data transfer/control to PC, trigger functions, alarm features, data storage options, capturing modes, search and calculation functions.
  • Storage: Built-in RAM (up to 4 million samples per channel), built-in Flash (4 GB), external USB and SD card support.
  • Capturing Mode: Normal, Ring, Relay with different specifications for each mode.
  • Operating Environment: 0 to 40 ºC, 5 to 85 % RH (non-condensed)
  • Power Source: AC adapter (100 to 240 V AC, 50/60 Hz), DC power (8.5 to 24 V DC), battery pack (optional)
  • Dimensions: Approx. 260 x 161 x 83 mm, weight approx. 1.7 kg
  • Software: Windows-compatible (GL980_2000-APS)

Analog Input Specifications:

  • Number of Channels: 8 isolated channels
  • Input Terminal: Isolated BNC connectors and Screw terminals
  • Sampling Speed: 1 M Samples/s to 1 Sample/min
  • Measurement Range: Voltage (DC), DC-RMS, Temperature (Thermocouple), Humidity
  • A/D Converter: 16-bit (effective resolution: 1/40000 of the measuring full range)
  • Measurement Accuracy: Varies with the type of measurement

External Input & Output Signal Specifications:

  • Input/Output: Logic or Pulse (4 channels), Trigger/Sampling (1 channel)
  • Input Signal Specification: Logic/Pulse voltage range, External trigger/sampling voltage range, measurement modes, etc.
  • Output Signal: Alarm output, Trigger output

Software Specifications:

  • Supported OS: Windows 10, 8.1, 8, 7
  • Functions: Control of GL980/GL2000, real-time data capture, data format conversion, etc.

Standard Accessories:

  • AC adapter, Quick start guide, CD-ROM with software and manual, Cover, Tilt stand set, Screws for input terminal, Ferrite core

Optional Accessories:

  • Input/Output cables, DC drive cable, Humidity sensor, Battery pack, Storage case, Various input cables/adapters

GL100

GL100: Versatile Data Acquisition System

Features
  • Multifunction Input Modules: Tailored modules for specific measurements, from temperature and humidity to AC and UV intensity.
  • Software Support: Access monitoring and control tools via PC or smart devices, offering both general-purpose and industry-specific applications.
  • Industry-Specific Software: Specialized software for agriculture, logistics, and power industries, providing targeted data analysis and measurement insights.
  • Wireless Connectivity: Configurable for direct connections or LAN setups, enabling seamless data access and control.
  • Robust Data Handling: Ample storage options in the built-in memory or microSD card for extensive data capturing.
Specifications & Accessory

Main Unit:

  • Channels: Varies based on input modules used; measurement types are fixed per module.
  • Input Method: Various terminal types; output includes an alarm (1 channel) with a solid-state switch.
  • Interfaces: USB (micro USB B type connector), Wireless LAN (IEEE802.11b, approx. 40m range).
  • Storage: Built-in memory (approx. 4.9 MB RAM) and microSD memory card support.
  • Display: Backlit monochrome LCD (128 x 64 dots) for real-time monitoring and settings.
  • Functions: Real-time data capturing, alarm setting, trigger-based recording, USB and WLAN-based data output and control.
  • Alarm: Triggered by set measurement conditions.
  • Power: Alkaline battery (AA x 2) or USB bus-power (5V, 200 mA).
  • Environment: -10 °C to 50 °C operating temperature, up to 80% RH (non-condensed) humidity.
  • Dimensions: Approx. 66 x 100 x 27 mm, Weight: 125 g (GL100-N) / 130 g (GL100-WL).

Sensor Modules:

  • Various Modules: Temperature & Humidity, Acceleration & Temperature, Illuminance & UV, Carbon Dioxide, AC Current Sensor, Voltage & Temperature, Thermistor Sensor.
  • Specifications: Each module offers specific measuring ranges, accuracy, response times, and operating environments tailored to its function.

Accessories:

  • Module Extension Cable (GS-EXC): 1.5m cable to connect all input modules.
  • AC Adapter: Recommended for USB-powered modules (not included).

GL7000

Step up your data collection game with the Graphtec GL7000

Features
  • Module Flexibility: Enables diverse measurements due to flexible combinations and the addition of various measurement types to a module.
  • Voltage Modules: Includes different voltage-based modules like GL7-V, GL7-M, GL7-HSV, GL7-HV, GL7-DCB, GL7-CHA, GL7-DCO, GL7-L/P.
  • Expandability: Up to 10 input/output modules can be attached to one main unit, accommodating a wide variety of measurements.
  • Mixing Measurements: Different types of modules can be mixed, maintaining the maximum sampling speed even with increased module numbers.
  • Sync and Control: Multiple GL7000 units can be synchronized and connected to a PC through LAN or USB.
  • Display Module: Equipped with a touch panel for convenient on-site operation and remote configuration.
  • Data Storage: Offers various storage options like built-in RAM, Flash memory, SD cards, and SSD modules for extensive data capture.
  • Sampling Speeds: Varies across modules and storage devices, ensuring high-speed sampling even with multiple modules attached.
  • Useful Functions: Includes dual-sampling, relay recording, ring mode, backup data creation, and more for efficient recording and replaying.
  • Interface and Connectivity: Supports Ethernet, USB2.0, FTP server functions, and SDK for custom application development.
  • Additional Tools (Optional): Carrying tool, storage case, input connectors, extension cables, etc., to enhance portability and connectivity.
Specifications & Accessory

GL7000 Specifications:

  • Model Number: GL7000
  • Module Support: Up to 10 modules (excluding Display module or SSD module)
  • Input Channels: Max. 112 channels in 1 GL7000
  • Input/Output Signals: Start/Stop, External trigger, External sampling, Auto balance
  • Signal Types: Contact (relay), Open collector, Voltage
  • Trigger & Alarm Outputs: Trigger, Busy, Alarm (10 channels)
  • Trigger Source: Measured signal, Alarm, External signal, Clock, Week, or Time
  • Data Capture Functions: Pre-trigger, Calculation (Addition, Subtraction, Multiplication, Division), Statistical analysis, FFT analysis, Annotation, Message/Marker functions, Resume after power failure
  • Interface: Ethernet, USB 2.0
  • Network Functions: WEB server, FTP server, FTP client, NTP client, DHCP client
  • Storage: Built-in RAM, Flash memory, External SD card, SSD module

Software Specifications (GL-Connection):

  • Model Name: GL-Connection
  • Supported OS: Windows 10/8.1/8/7 (32/64-bit)
  • Functions: Control GL7000, Real-time data capture, Replay data, Data format conversion
  • Data Format: Binary format, CSV format
  • Displayed Information: Analog waveform, Logic waveform, Pulse waveform, Digital values
  • Functions: Statistical calculation, Search, Alarm, Cursor synchronization, Remote lock release

Display Module GL7-DISP:

  • Display Device: 5.7-inch TFT color LCD monitor (640 x 480 dots)
  • Operation: Touch panel, Cursor keys
  • Displayed Language: English, French, German, Chinese, Korean, Japanese
  • Information Displayed: Y-T waveform with digital values, XY graph, Digital value

SSD Module GL7-SSD:

  • Storage: Solid state disk (SSD)
  • Capacity: Approx. 128GB
  • Sampling Speed: Varies with the number of attached modules

Humidity Sensor B-530:

  • Temperature Range: -25 to 80°C
  • Humidity Range: 0 to 100% RH
  • Accuracy: ±3% RH (5 to 98% RH at 25°C)

Accessories:

  • Sync Cable, Carrying Tool, Storage Case, Probe Set for Logic Input, Input Cables (BNC/Banana/Alligator clip), Humidity Sensor, Shunt Resistance, Extension Cables, Terminal Holding Brackets, Output Cables
Scroll to Top
